Gast 0523 Rotary Vane Air Compressor

The Red Alert P101-2 Control Panel is a superior replacement for panels used with septic tank aerators. This control panel is compatible for use with air pumps, vane pumps, regenerative blowers, and linear style aerators manufactured by brands such as Whirlwind®, Hiblow®, Gast®, Secoh®, as well as alternative high-quality replacement units like the ones produced by Septic Tank Parts. This unit is not to be used with shaft-style aeration systems.

For shaft-style aerators, use the Red Alert P101FA-2 Control Panel.

The Red Alert control panel is manufactured for longevity in indoor and outdoor use. Crafted from industrial-grade plastics, UL-rated weather-resistant housing, and anti-corrosive zinc-plated screw terminals, this control panel is resistant to wear and temperature extremes.

With the Red Alert™ 24-time control technology, the P101-2 is completely programmable with a control timer, warning light, and a 3-position toggle switch that allows the unit to be on/auto; off; or in continuous run mode. The ability to program down to 15-minute intervals gives you precise control over your aerator scheduling.

Warranty

We offer a 2-year limited warranty on Red Alert Control Panels.

Whirlwind® STA Series Septic Air Pumps are dependable, energy-efficient aerators that offer extremely quiet operation and excellent long life. Whirlwind® linear air pumps use diaphragms to compress and move air through heavy-duty tubing into the wastewater of your septic aeration tank. The Whirlwind® STA80N Septic Air Pump operates 80 LPM at 2.18 PSI with a maximum continuous operating pressure of 4.35 PSI. The STA80N also achieves a maximum open air flow of 3.9 CFM. Linear diaphragm air pumps are effective pumps for septic aeration and have been widely used for pond aeration, as well as applications in medical and laboratory settings.

The Whirlwind® STA80N Septic Air Pump is a compatible septic tank pump replacement for original equipment manufacturer (OEM) 80 LPM models including: Alita AL-80, Blue Diamond ET-80/ETX-80, FujiMAC MAC80R II, Hiblow HP-80, Secoh EL-80/JDK-80, and Thomas AP-80/AP-80H.

Warranty

We offer a 2-Year Limited Warranty on all Whirlwind Septic Air Pumps.

The Internal Filter for Gast Rotary Vane Air Compressors requires two filters per pump. The AK524 filter element is used on oil-less models with internal filtration which include models 0323, 0523, RV03, RV05, AT03, AT05, 0823 and 1023. Annual replacement is recommended.

Include two (2) felt filters

The B343B External Gast Filter & Element is the complete external assembly for Gast models 0323, 0523, RV03, RV05, AT03 and AT05. Assembly includes (2) external filters, one filter stem and one end cap. It is recommended the filter be changed every 6 months.

The Fine Bubble Air Diffuser delivers fine air bubbles for maximum aeration in your septic system.

3/4" Male pipe threaded connection

9" diameter

The B344A-K External Felt Filter is the replacement part for Gast B343B External Filter Assembly. TWO REQUIRED per assembly for models 0323, 0523, AT03, AT05, RV03 and RV05.

Includes two (2) filters

t50 micron filters

Replacement End Cap Assembly for Gast 0523, 1023, AT03 and AT05 Rotary Vane Air Compressors.

Includes One (1) endcap stem One (1) filter One (1) o-ring

The SSIK478 Vane Kit is the compatible repair kit for Gast 0523 and 0323 oil-less models with internal filtration. The kit includes four vanes, one gasket, two internal filters and two o-rings. A new rebuild kit is recommended every two years.

Gast compressors provide many years of dependable service but due to continual wear over time some compressor components may need to be replaced in order to continue to provide the proper air flow. Instead of purchasing a new pump, you may need to just replace some internal components.

Vane Dimensions 1-1/4" L x 1-3/8" W

Vane Thickness 1/8"
